Cisco UCS C240 M6 Rack Server

Overview Cisco UCS C240 M6 Rack Server

The Cisco UCS C240 M6 Rack Server is a powerful 2-socket, 2-Rack-Unit (2RU) server designed to meet the demands of a wide range of storage and I/O-intensive workloads. Here are the key features of the Cisco UCS C240 M6:

Processor: Supports the third-generation Intel Xeon Scalable CPU, with up to 40 cores per socket.
Memory: Up to 32 DDR4 DIMMs, including support for higher density DDR4 DIMMs (16 DIMMs per socket). It also supports 16x Intel Optane persistent memory modules for a total of up to 12 TB of memory.
Expansion Slots: Offers up to 8 PCIe Gen 4.0 expansion slots, along with a modular LAN-on-motherboard (mLOM) slot.
Network Connectivity: Supports Cisco UCS VIC 1400 Series adapters as well as third-party options. Features dual embedded Intel x550 10GBASE-T LAN-on-motherboard (LOM) ports.
Storage: Provides flexibility with up to 28 hot-swappable Small-Form-Factor (SFF) SAS/SATA or NVMe drives, including options for SAS/SATA, NVMe, or a combination of both. It also supports up to 16 Large-Form-Factor (LFF) drives with options for rear SFF (SAS/SATA/NVMe) disk drives.
RAID Controller: Supports a 12-Gbps SAS modular RAID controller in a dedicated slot, freeing up the remaining PCIe Gen 4.0 expansion slots for other cards.
Boot Options: Offers M.2 boot options with support for up to 960 GB with optional hardware RAID.
GPU Support: Capable of supporting up to five GPUs.
Modular LAN-on-motherboard (mLOM): Features a slot that can accommodate a Cisco UCS Virtual Interface Card (VIC) without consuming a PCIe slot, offering quad port 10/40 Gbps or dual port 40/100 Gbps network connectivity.

These features make the Cisco UCS C240 M6 Rack Server an ideal choice for organizations looking for high-performance, scalable, and efficient computing solutions for their data-intensive workloads.

Spesifikasi Cisco UCS C240 M6 Rack Server

Item	Specifications
Form factor	2RU rack server
Processors	3rd Generation Intel Xeon Scalable processors (1 or 2)
Memory	32 DDR4 DIMM slots: 16, 32, 64, 128 and 256 GB up to 3200 MHz Support for the Intel Optane DC persistent memory (128G, 256G, 512G)
PCIe expansion	8 PCIe 4.0 slots plus 1 dedicated 12-Gbps RAID controller slot and 1 dedicated mLOM slot
RAID controllers	Internal controllers: Cisco 12-Gbps Modular RAID Controller (PCIe 4.0) with 2G Raid controller with 4GB cache for up to 28 SAS/SATA drives. Also a 12G SAS HBA for up to 16 drives (up to 2 HBAs in SX SKU), 4-GB Flash-Backed Write Cache (FBWC), providing enterprise-class data protection for up to 10 SAS and SATA Hard Disk Drives (HDDs), SSDs, or NVMe PCIe SSDs; or Cisco 12-Gbps Modular SAS Host Bus Adapter (HBA) External controller: Cisco 12-Gbps 9500-8e SAS HBA
Internal storage	Backplane options: Up to 28 x 2.5-inch SAS and SATA HDDs and SSDs (up to 4 NVMe PCIe drives) Up to 26 x 2.5-inch NVMe PCIe SSDs (All direct attach Gen4 x4) Up to 16 x 3.5-inch SAS and SATA HDDs and SSDs and optional 2 rear 2.5-inch HDDs and SSDs (up to 4 NVMe PCIe drives)
Embedded Network Interface Cards (NICs)	Dual 10GBASE-T Intel x550 Ethernet ports
mLOM	Dedicated mLOM slot that can flexibly accommodate 10/25/40, and 100-Gbps adapters
Power supplies	Hot-pluggable, redundant 1050W AC, 1050W DC, 1600W AC, and 2300W AC
Other storage	Dedicated Baseboard Management Controller (BMC) FlexMMC for utilities (on board) Dual M.2 SATA SSDs with HW Raid support
Management	Cisco Intersight Cisco Integrated Management Controller (IMC) Cisco UCS Manager
Rack options	Cisco ball-bearing rail kit with optional reversible cable management arm
Hardware and software interoperability	See the Cisco Hardware and Software Interoperability List for a complete listing of supported operating systems and peripheral options.
